Product Information
GST-Trap is an affinity resin for IP of GST fusion proteins. It consists of a GST Nanobody/ VHH coupled to agarose beads.
| Description | The GST-Trap Agarose Kit contains GST-Trap Agarose, lysis, wash, and elution buffers for efficient immunoprecipitation of GST-fusion proteins and their interacting factors.
• Effectively immunoprecipitates low expressed GST-fusion proteins • Considerably higher affinity than glutathione cellulose and other affinity resins • Strong binding even under harsh washing conditions • No heavy & light chains in your downstream application |
| Applications | IP, CoIP, ChIP, RIP |
| Specificity/Target | Glutathione S-Transferase (GST) from Schistosoma japonicum |
| Binding capacity | 7.5-10 μg of recombinant GST per 25 μL bead slurry |
| Conjugate | Agarose beads; bead size: ~ 90 µm (cross-linked 4 % agarose beads) |
| Elution buffer | SDS sample buffer 0.2 M glycine pH 2.5 |
| Wash buffer compatibility | 4 M urea, 2 M NaCl, 10 mM DTT, 2 % Nonidet P40 Substitute, 1 % Triton X-100 |
| Type | Nanobody |
| Class | Recombinant |
| Host | Alpaca |
| Affinity (KD) | Dissociation constant KD of 1 nM |
| Compatibility with mass spectrometry | The GST-Trap is optimized for on-bead digestion. For the application note, please click here: On-bead digest protocol for mass spectrometry |
| RRID | AB_2631414 |
| Storage Buffer | 20% ethanol |
| Storage Condition | Shipped at ambient temperature. Upon receipt store at 4°C. Stable for one year. Do not freeze! |
Kit components
| Component | Description |
|---|---|
| GST-Trap Agarose | 20 reactions (500 µL) |
| Lysis buffer | Optimized for cytoplasmatic proteins and mammalian cell lysis |
| RIPA buffer | Optimized for nuclear/chromatin proteins and mammalian cell lysis |
| Wash buffer | Removal of unwanted proteins, peptides, etc. |
| Dilution buffer | Dilution of cell lysate |
| Elution buffer | For acidic elution |
Documentation
| SDS |
|---|
| stak_SDS_GST-Trap Agarose Kit (EN) |
| Datasheet |
|---|
| GST-Trap Agarose, Kit for Immunoprecipitation Datasheet |
| Trouble shooting |
|---|
| Troubleshooting guide immunoprecipitation (PDF) |
| Whitepaper |
|---|
| Immunoprecipitation of GST- and MBP-fusion proteins (PDF) |
