TurboGFP-Trap Magnetic Agarose is an affinity reagent for immunoprecipitation (IP) of TurboGFP fusion proteins. It consists of an anti-TurboGFP VHH/ Nanobody that is coupled to magnetic agarose beads.
| Description | The TurboGFP-Trap® Magnetic Agarose Kit contains TurboGFP-Trap Magnetic Agarose, lysis, wash, and elution buffers for efficient immunoprecipitation of TurboGFP-fusion proteins and their interacting factors.
• Fast, reliable & efficient one-step immunoprecipitation • Ready-to-use • No heavy & light antibody chains on the SDS-PAGE • Stable under harsh washing conditions • Suitable for downstream mass spec analysis |
| Applications | IP, CoIP |
| Specificity/Target | TurboGFP, CopGFP, maxGFP, maxFP-Green For the complete list, please click here: Fluorescent protein specificity table |
| Binding capacity | 7.5-10 μg of recombinant TurboGFP per 25 μL bead slurry |
| Conjugate | Magnetic agarose beads; bead size: ~40 µm (cross-linked 6 % magnetic agarose beads) |
| Elution buffer | SDS sample buffer 0.1 mM citrate acid pH 3.0 |
| Wash buffer compatibility | 6 M urea, 2 M NaCl, 10 mM DTT, 2 % Nonidet P40 Substitute, 1 % Triton X-100, 0.2 % SDS |
| Type | Nanobody |
| Class | Recombinant |
| Host | Alpaca |
| Affinity (KD) | Dissociation constant KD of 0.5 nM |
| Compatibility with mass spectrometry | The TurboGFP-Trap is optimized for on-bead digestion. For the application note, please click here: On-bead digest protocol for mass spectrometry |
| RRID | AB_2827597 |
| Storage Buffer | 20% ethanol |
| Storage Condition | Shipped at ambient temperature. Upon receipt store at 4°C. Stable for one year. Do not freeze! |
Kit components
| Component | Description |
|---|---|
| TurboGFP-Trap Magnetic Agarose | 20 reactions (500 µL) |
| Lysis buffer | Optimized for cytoplasmatic proteins and mammalian cell lysis |
| RIPA buffer | Optimized for nuclear/chromatin proteins and mammalian cell lysis |
| Wash buffer | Removal of unwanted proteins, peptides, etc. |
| Dilution buffer | Dilution of cell lysate |
| Elution buffer | For acidic elution |
